Nmap Cheat Sheet Welcome to my Nmap Cheat Sheet page! Nmap is one of my favorite tools not only for pentesting or security purposes but also as one of my go-to troubleshooting tools.
Nmap 2.00 was released on December 12, 1998. Can you believe it? I have been using Nmap since the early 2000s, and although I have tried MANY tools that do the same thing, nothing has yet to beat its place in my toolbox.
If you see an error, something I missed, or have a better way of doing something, please contact me.
Resources: Nmap – https://nmap.org/
The Nmap Handbook: A Deep Dive into Network Mapping and Scanning
The Official Nmap Project Guide to Network Discovery and Security Scanning – The orginal and still one of the best Nmap resources
Scanning Command Syntax: nmap [scan types] [options] {IP-Address specification}
Scan a
SWITCH EXAMPLE DESCRIPTION nmap 10.1.1.1 Scan a single IP nmap 10.1.1.1 10.1.1.8 Scan specific IPs nmap 10.1.1.1-254 Scan a range nmap scanme.nmap.org Scan a domain nmap 10.1.1.0/24 Scan using CIDR notation -iL nmap -iL targets.txt Scan targets from a file -iR nmap -iR 100 Scan 100 random hosts -exclude nmap -exclude 10.1.1.254 Exclude listed hosts
Nmap Scan Techniques
SWITCH EXAMPLE DESCRIPTION -sS nmap 10.1.1.1 -sS TCP SYN port scan (Default) -sT nmap 10.1.1.1 -sT TCP connect port scan (Default without root privilege) -sU nmap 10.1.1.1 -sU UDP port scan -sA nmap 10.1.1.1 -sA TCP ACK port scan -sW nmap 10.1.1.1 -sW TCP Window port scan -sM nmap 10.1.1.1 -sM TCP Maimon port scan
Host Discovery
SWITCH EXAMPLE DESCRIPTION -sL nmap 10.1.1.1-3 -sL No Scan. List targets only -sn nmap 10.1.1.0/24 -sn Disable port scanning. Host discovery only. -Pn nmap 10.1.1.1-5 -Pn Disable host discovery. Port scan only. -PS nmap 10.1.1.1-5 -PS22-25,80 TCP SYN discovery on port x. Port 80 by default -PA nmap 10.1.1.1-5 -PA22-25,80 TCP ACK discovery on port x. Port 80 by default -PU nmap 10.1.1.1-5 -PU53 UDP discovery on port x. Port 40125 by default -PR nmap 10.1.1.1-1/24 -PR ARP discovery on local network -n nmap 10.1.1.1 -n Never do DNS resolution
Port Specification
SWITCH EXAMPLE DESCRIPTION -sV nmap 10.1.1.1 -sV Attempts to determine the version of the service running on port -sV -version-intensity nmap 10.1.1.1 -sV -version-intensity 8 Intensity level 0 to 9. Higher number increases possibility of correctness -sV -version-light nmap 10.1.1.1 -sV -version-light Enable light mode. Lower possibility of correctness. Faster -sV -version-all nmap 10.1.1.1 -sV -version-all Enable intensity level 9. Higher possibility of correctness. Slower -A nmap 10.1.1.1 -A Enables OS detection, version detection, script scanning, and traceroute
OS Detection
SWITCH EXAMPLE DESCRIPTION -O nmap 10.1.1.1 -O Remote OS detection using TCP/IP stack fingerprinting -O -osscan-limit nmap 10.1.1.1 -O -osscan-limit If at least one open and one closed TCP port are not found it will not try OS detection against host -O -osscan-guess nmap 10.1.1.1 -O -osscan-guess Makes Nmap guess more aggressively -O -max-os-tries nmap 10.1.1.1 -O -max-os-tries 1 Set the maximum number x of OS detection tries against a target -A nmap 10.1.1.1 -A Enables OS detection, version detection, script scanning, and traceroute
SWITCH EXAMPLE DESCRIPTION -T0 nmap 10.1.1.1 -T0 Paranoid (0) Intrusion Detection System evasion -T1 nmap 10.1.1.1 -T1 Sneaky (1) Intrusion Detection System evasion -T2 nmap 10.1.1.1 -T2 Polite (2) slows down the scan to use less bandwidth and use less target machine resources -T3 nmap 10.1.1.1 -T3 Normal (3) which is default speed -T4 nmap 10.1.1.1 -T4 Aggressive (4) speeds scans; assumes you are on a reasonably fast and reliable network -T5 nmap 10.1.1.1 -T5 Insane (5) speeds scan; assumes you are on an extraordinarily fast network
SWITCH EXAMPLE INPUT DESCRIPTION -host-timeout <time> 1s; 4m; 2h Give up on target after this long -min-rtt-timeout/max-rtt-timeout/initial-rtt-timeout <time> 1s; 4m; 2h Specifies probe round trip time -min-hostgroup/max-hostgroup <size<size> 50; 1024 Parallel host scan group sizes -min-parallelism/max-parallelism <numprobes> 10; 1 Probe parallelization -max-retries <tries> 3 Specify the maximum number of port scan probe retransmissions -min-rate <number> 100 Send packets no slower than <number> per second -max-rate <number> 100 Send packets no faster than <number> per second
NSE Scripts
SWITCH EXAMPLE DESCRIPTION -sC nmap 10.1.1.1 -sC Scan with default NSE scripts. Considered useful for discovery and safe -script default nmap 10.1.1.1 -script default Scan with default NSE scripts. Considered useful for discovery and safe -script nmap 10.1.1.1 -script=banner Scan with a single script. Example banner -script nmap 10.1.1.1 -script=http* Scan with a wildcard. Example http -script nmap 10.1.1.1 -script=http,banner Scan with two scripts. Example http and banner -script nmap 10.1.1.1 -script “not intrusive” Scan default, but remove intrusive scripts -script-args nmap -script snmp-sysdescr -script-args snmpcommunity=admin 10.1.1.1 NSE script with arguments
NSE Script Examples
COMMAND DESCRIPTION nmap -Pn -script=http-sitemap-generator scanme.nmap.org http site map generator nmap -n -Pn -p 80 -open -sV -vvv -script banner,http-title -iR 1000 Fast search for random web servers nmap -Pn -script=dns-brute domain.com Brute forces DNS hostnames guessing subdomains nmap -n -Pn -vv -O -sV -script smb-enum*,smb-ls,smb-mbenum,smb-os-discovery,smb-s*,smb-vuln*,smbv2* -vv 10.1.1.1 Safe SMB scripts to run nmap -script whois* domain.com Whois query nmap -p80 -script http-unsafe-output-escaping scanme.nmap.org Detect cross site scripting vulnerabilities nmap -p80 -script http-sql-injection scanme.nmap.org Check for SQL injections
Firewall / IDS Evasion
SWITCH EXAMPLE DESCRIPTION -f nmap 10.1.1.1 -f Requested scan (including ping scans) use tiny fragmented IP packets. Harder for packet filters -mtu nmap 10.1.1.1 -mtu 32 Set your own offset size -D nmap -D 10.1.1.101,10.1.1.102,10.1.1.103,10.1.1.23 10.1.1.1 Send scans from spoofed IPs -D nmap -D decoy-ip1,decoy-ip2,your-own-ip,decoy-ip3,decoy-ip4 remote-host-ip Above example explained -S nmap -S www.twitter.com www.facebook.com Scan Facebook from twitter (-e eth0 -Pn may be required) -g nmap -g 53 10.1.1.1 Use given source port number -proxies nmap -proxies http://10.1.1.1::8080, http://10.1.1.2:8080 10.1.1.1 Relay connections through HTTP/SOCKS4 proxies -data-length nmap -data-length 200 10.1.1.1 Appends random data to sent packets
Output Control
SWITCH EXAMPLE DESCRIPTION -oN nmap 10.1.1.1 -oN normal.file Normal output to the file normal.file -oX nmap 10.1.1.1 -oX xml.file XML output to the file xml.file -oG nmap 10.1.1.1 -oG grep.file Grepable output to the file grep.file -oA nmap 10.1.1.1 -oA results Output in the three major formats at once -oG – nmap 10.1.1.1 -oG – Grepable output to screen. -oN -, -oX – also usable -append-output nmap 10.1.1.1 -oN file.file -append-output Append a scan to a previous scan file -v nmap 10.1.1.1 -v Increase the verbosity level (use -vv or more for greater effect) -d nmap 10.1.1.1 -d Increase debugging level (use -dd or more for greater effect) -reason nmap 10.1.1.1 -reason Display the reason a port is in a particular state, same output as -vv -open nmap 10.1.1.1 -open Only show open (or possibly open) ports -packet-trace nmap 10.1.1.1 -T4 -packet-trace Show all packets sent and received -iflist nmap -iflist Shows the host interfaces and routes -resume nmap -resume results.file Resume a scan
Nmap Output Examples
COMMAND DESCRIPTION nmap -p80 -sV -oG – -open 10.1.1.1/24 | grep open Scan for web servers and grep to show which IPs are running web servers nmap -iR 10 -n -oX out.xml | grep “Nmap” | cut -d ” ” -f5 > live-hosts.txt Generate a list of the IPs of live hosts nmap -iR 10 -n -oX out2.xml | grep “Nmap” | cut -d ” ” -f5 >> live-hosts.txt Append IP to the list of live hosts ndiff scanl.xml scan2.xml Compare output from nmap using the ndif xsltproc nmap.xml -o nmap.html Convert nmap xml files to html files grep ” open ” results.nmap | sed -r ‘s/ +/ /g’ | sort | uniq -c | sort -rn | less Reverse sorted list of how often ports turn up
Misc Nmap Flags
SWITCH EXAMPLE DESCRIPTION -6 nmap -6 2607:f0d0:1002:51::3 Enable IPv6 scanning -h nmap -h nmap help screen -open nmap -open Show open ports only
Useful Nmap Commands
COMMAND DESCRIPTION nmap -iR 10 -PS22-25,80,113,1050,35000 -v -sn Discovery only on ports x, no port scan nmap 192.168.1.1-1/24 -PR -sn -vv Arp discovery only on local network, no port scan nmap -iR 10 -sn -traceroute Traceroute to random targets, no port scan nmap 192.168.1.1-50 -sL -dns-server 192.168.1.1 Query the Internal DNS for hosts, list targets only nmap 192.168.1.1 –packet-trace
Show the details of the packets that are sent and received during a scan and capture the traffic
Pings and Traceroutes
COMMAND DESCRIPTION nmap -sP 10.1.1.1 Ping scan only nmap -PU 10.1.1.1 UDP ping scan nmap -PE 10.1.1.1 ICMP echo ping nmap -PO 10.1.1.1 IP protocal ping nmap -PR 10.1.1.1 ARP ping nmap -Pn 10.1.1.1 Scan without pinging nmap -traceroute 10.1.1.1 Traceroute
